Description:-
The Extrusion system is the only system that combines two major processes – recycling and compounding – into one. Simplicity at its best.
The extruder combines the familiar, superior, plastification and homogenization of a co-rotating parallel twin screw extruder with the specific advantages of the conical screw design; a key element of this integrated recycling and compounding system. The extruder is perfectly suited for any application when a variety of product requirements need an individual, high-quality solution.
Models | KRP-65 | KRP-75 | KRP-90 | KRP-100 | KRP-125 | KRP-150 |
Screw Dia. mm | 65 | 75 | 90 | 100 | 125 | 150 |
Main Motor KW | 15 | 20 | 30 | 40 | 50 | 75 |
*Max. Output Kg./hr. | 60-70 | 70-90 | 110-130 | 170-200 | 200-250 | 270-300 |
Strand Ctr. blades/ Load KW | 6 / 0.75 | 6 / 0.75 | 8 / 1.0 | 12 / 1.5 | 12 / 1.5 | 16 / 2.0 |
