| KMT Models | MM | 50/H/1 | 200/H/1 | 200/H/2 | 500/H/1 | 500/H/2 |
| Screw Diameter | MM | 25 | 30 | 40 | 40 | 45 |
| L.D. Ratio | L/D | 22:1 | 22:1 | 22:1 | 22:1 | 22:1 |
| Blowing Capacity | ML | 50 | 200 | 200 | 500 | 500 |
| Screw Speed | R.P.M | 0-75 | 0-75 | 0-75 | 0-75 | 0-75 |
| Plasticzing Cap | Kg/Hr. | 4/5 | 7/8 | 14/18 | 15/18 | 15/20 |
| Heating Zone | Nos. | 3 | 5 | 5 | 5 | 5 |
| Maximum Die Dia HD/PVC | HD/PVC | 15 | 25 | 25 | 45 | 45/50 |
| Mould Opening Stroke | MM | 100 | 125 | 125 | 150 | 150 |
| Min Mould Thickness | MM | 102 | 135 | 135 | 180 | 180 |
| Mould Length | MM | 150 | 200 | 200 | 270 | 270 |
| Mould Width | MM | 125 | 140 | 140 | 170 | 170 |
| Dry Cycle/min | Nos. | 20 | 20 | 15 | 15 | 15 |
| Max. Container Dia | MM | 40 | 60 | 60 | 75 | 75 |
| Extruder Drive | HP | 2 | 3 | 5 | 5 | 7.5 |
| Hydraulic Motor | HP | 0 | 0 | 3 | 3 | 5 |
| Blowers | HP | 0 | 0 | 0 | 0 | 0 |
| Heating Load | HP | 5 | 6 | 10 | 10 | 12 |
| Total Power of M/C | HP | 7 | 9 | 18 | 18 | 25 |
| Main Cable Rating | MM2Amp | 2.5/19 | 4.0/26 | 10/42 | 10/42 | 16/57 |
| Bobbing | OPT | OPT | OPT | OPT | ||
| Parison Programmer | OPT | OPT | OPT | OPT | OPT | |
| Hot Wire Cutter4 | OPT | OPT | OPT | OPT | OPT | |
| Bottom Blowing System | OPT | OPT | OPT | OPT | OPT | |
| Hydraulic Blowing | OPT | OPT | OPT | OPT | OPT | |
| Oil Tank Capacity | Ltrs. | 0 | 0 | 130 | 150 | 180 |
| M/C Diamension (L X W X H) | Mtrs. | 1.7x0.8x2 | 1.5x0.8x2 | 1.9x1.5x2.1 | 1.9x1x2.2 | 2.1x1.7x2.2 |
| Machine & Panel Weight | Kgs. | 500 | 600 | 1400 | 1250 | 1800 |
| Air Requirement | C.F.M | 8 | 8 | 9 | 9 | 9 |
Blow Moulding Machine-2
| KMT Models | MM | 1000/H/1 | 1000/H/2 | 2000/H/1 | 2000/H/2 | 5000/H/1 | 5000/H/2 |
| Screw Diameter | MM | 45 | 50 | 50 | 65 | 65 | 90 |
| L.D. Ratio | L/D | 22:1 | 22:1 | 22:1 | 22:1 | 22:1 | 22:1 |
| Blowing Capacity | ML | 1000 | 1000 | 2000 | 2000 | 5000 | 5000 |
| Screw Speed | RPM | 0-75 | 0-75 | 0-75 | 0-75 | 0-75 | 0-75 |
| Plasticzing Cap | Kg/Hr. | 15/20 | 22/26 | 22/28 | 40/45 | 40/45 | 90/100 |
| Heating Zones | Nos. | 5 | 5 | 5 | 6 | 6 | 8 |
| Maximum Die Dia | HD | 60 | 68 | 80 | 80 | 140 | 140 |
| Maximum Die Dia | PVC | 40 | 50 | 60 | 60 | - | - |
| Mould Opening Storke | MM | 185 | 185 | 200 | 200 | 250 | 250 |
| Min Mould Thickness | MM | 180 | 180 | 205 | 260 | 260 | 260 |
| Mould Length | MM | 340 | 340 | 350 | 350 | 450 | 450 |
| Mould Width | MM | 220 | 220 | 250 | 250 | 320 | 320 |
| Dry Cycle/Min | Nos. | 15 | 12 | 12 | 10 | 10 | 8 |
| Max. Container Dia. | MM | 125 | 125 | 150 | 150 | 200 | 200 |
| Extruder Drive | HP | 7.5 | 10 | 10 | 15 | 15 | 30 |
| Hydraulic Motor | HP | 3 | 5 | 5 | 7.5 | 7.5 | 10 |
| Blowers | HP | 0 | 0 | 0 | 0 | 0 | 0 |
| Heating Load | HP | 12 | 14 | 14 | 20 | 20 | 30 |
| Total Power of M/C. | HP | 22.5 | 29 | 29 | 43 | 43 | 70 |
| Main Cable Rating | 16/57 | 25/71 | 25/71 | 35/91 | 25/91 | 95/200 | |
| Bobbing | OPT | OPT | OPT | OPT | OPT | OPT | |
| Parison Programmer | OPT | OPT | OPT | OPT | OPT | OPT | |
| Hot Wire Cutting | OPT | OPT | OPT | OPT | OPT | OPT | |
| Hydraulic Blowing | OPT | OPT | OPT | OPT | OPT | OPT | |
| Oil Tank Capacity | Ltrs. | 150 | 200 | 170 | 270 | 250 | 300 |
| M/c. Diamension (L X W X H) | Mtrs. | 1.9x1x1.2 | 2.3x2.2x2.2 | 2.3x1.4x2.5 | 2.7x2.2x2.5 | 2.8x1.8x2.5 | 3.5x2.5x2.7 |
| Machine & Panel Weight | Kgs. | 1700 | 2700 | 2000 | 4200 | 4000 | 7000 |
| Air Requirement | C.F.M | 10 | 15 | 12 | 15 | 15 | 20 |
