| Models | KBF-50 | KBF-65 | KBF-75 | KBF-90 |
| Screw Dia. mm | 50 | 65 | 75 | 90 |
| Main Motor KW | 9.3 | 15 | 22.4 | 37.0 |
| Die type | Spiral | Spiral | Spiral | Spiral |
| Lay flat width mm | 700 | 950 | 1350 | 1850 |
| *Max. Output Kg./hr. | 32-37 | 50-60 | 80-90 | 130-150 |
| Nip Roller width mm | 800 | 1100 | 1500 | 2000 |
| Winder Type | Surface | Center | Center | Center |
| Connected Load KW | 18.00 | 28.00 | 41.5 | 64.00 |
